Diamond cut-off wheel DG FL 76x1.6x10 mm PSF for cutting tiles, high cutting quality

Technical information

Abrasive: Diamond
Dia. external: 76 mm
Dia. hole: 10 mm
Height, coating: 7 mm
Max. RPM: 11000 RPM
Shape: 1A1R / DG FL
Version: FL
Width: 1.3 mm
Packaging unit: 1 piece

Description

PFERD TOOLS diamond cut-off wheels are manufactured in compliance with the highest quality and safety standards. They guarantee optimum cutting results and allow efficient processing of different materials, e.g. concrete, exposed aggregate concrete, clinker brick, hard stone, granite and other abrasive building materials. The product range offers the best tool for any application.

General-purpose continuous-edge tool for cutting without edge breakages on workpieces with high-quality surfaces. High cutting performance and ideal tool life.

The version with a continuous rim is suitable for very fine cuts, e.g. tiles.

Special features

High diamond qualities.
Good cutting characteristics and short cutting times.
Good ease of cutting and high economic efficiency.

Recommendations for use

If possible, wet grinding is to be preferred to dry grinding. This reduces tool wear, the risk of thermal damage to the workpiece and dust exposure.
Cut using only slight pressure in order to stop the tool overheating.
Suitable for use on angle grinders of all output levels.
